v2.9.4.0 – Aired @ 31/05/2026
BENCH ( Maps / No unlock required )
- CASE MD1CS069 TC299: Read ( Maps ) + Write ( Maps ) / Recovery / DTC Clear / Checksum(s)
- IVECO MD1CE102 CNG TC299: Read ( Maps ) + Write ( Maps ) / Recovery / DTC Clear / Checksum(s)
- IVECO MD1CE101 TC299: Read ( Maps ) + Write ( Maps ) / Recovery / DTC Clear / Checksum(s)
- IVECO MD1CS069 TC299: Read ( Maps ) + Write ( Maps ) / Recovery / DTC Clear / Checksum(s)
BENCH ( Service Mode )
- FORD MG1CS019 TC298: Read ( Int. Flash + Int. Eeprom + All[Backup] ) + Write ( Int. Flash + Int. Eeprom + All[Backup] ) / Recovery / Clone / Checksum(s)
- FORD MG1CS018 TC298: Read ( Int. Flash + Int. Eeprom + All[Backup] ) + Write ( Int. Flash + Int. Eeprom + All[Backup] ) / Recovery / Clone / Checksum(s)
- FORD MG1CS017 TC298: Read ( Int. Flash + Int. Eeprom + All[Backup] ) + Write ( Int. Flash + Int. Eeprom + All[Backup] ) / Recovery / Clone / Checksum(s)
- FORD MG1CS016 TC275: Read ( Int. Flash + Int. Eeprom + All[Backup] ) + Write ( Int. Flash + Int. Eeprom + All[Backup] ) / Recovery / Clone / Checksum(s)
- IVECO MD1CE102 TC299: Read ( Int. Flash + Int. Eeprom + All[Backup] ) + Write ( Int. Flash + Int. Eeprom + All[Backup] ) / Recovery / Checksum(s)
- IVECO MD1CE101 TC299: Read ( Int. Flash + Int. Eeprom + All[Backup] ) + Write ( Int. Flash + Int. Eeprom + All[Backup] ) / Recovery / Checksum(s)
- MAN MD1CE100 TC299: Read ( Int. Flash + Int. Eeprom + All[Backup] ) + Write ( Int. Flash + Int. Eeprom + All[Backup] ) / Recovery / Checksum(s)
SH725XX ( JTAG )
- JCB DELPHI DCM3.3+ SH72544R: Read + Write ( All / Int. Flash / Int. Eeprom ) / Recovery / Clone / Checksum(s)
IMPORTANT NOTES
- As you may note there are now two types of BENCH protocols for IVECO MD1CE101 & MD1CE102 control units. While the BENCH protocol for MAPs/Calibration works with units up to 2026 without the need for unlocking if you need to read/write the full contents of these units for any particular reason we can provide the service of unlocking the service mode as a mail-in to our office.
- Ford MD1/MG1 control units are clone-able provided there are no HSM exclusive sectors in TRICORE internal flash memory – this can be checked with BENCH service mode protocol by going to “INT. FLASH” tab and pressing “Show Sectors” after correct identification.
